Deye 50kW 3-Phase Hybrid HV Inverter Overview
The Deye 50kW Hybrid 3-Phase Inverter (model SUN-50K-SG01HP3-EU-BM) is engineered for high-efficiency solar power management. With a high-voltage battery range of 160V to 800V, this inverter enhances energy conversion while reducing heat dissipation. It supports a 1.3 DC/AC ratio and allows parallel operation of up to 10 inverters, making it ideal for scalable energy systems.
Key Features
- Efficient and Reliable Power Delivery:
- 100% unbalanced output per phase, max. output up to 50% rated power
- 230V/400V three-phase pure sine wave output
- Self-consumption with feed-in to the grid capability
- Auto-restart upon AC power recovery
- Advanced Battery Management:
- High-voltage battery compatibility (160V–800V)
- 100A maximum charging/discharging current
- Configurable charging voltage/current via LCD
- Six time periods for battery charging/discharging
- Supports parallel battery storage
- Smart Energy Optimization:
- Supports AC and DC coupling for retrofitting existing solar systems
- Time-of-use function for smart energy scheduling
- Smart load function for optimized power utilization
- Configurable AC/Solar/Generator charger priority
- Grid power limiting to prevent excess feed-in
- Superior Solar Performance:
- MPPT tracking for maximum solar efficiency
- Three-stage MPPT charging for battery longevity
- Four MPPT trackers with multiple input strings
- Robust Protection & Monitoring:
- Overload, temperature, and short-circuit protection
- Wi-Fi monitoring for real-time tracking
- Smart monitoring platform with remote shutdown capability
- Remote firmware updates and parameter adjustments
- Compatible with mains voltage and generator power
Technical Specifications
- Battery Input:
- Battery Type: Li-Ion
- Battery Voltage Range: 160V - 800V
- Max Charging/Discharging Current: 50A + 50A
- Battery Inputs: 2
- Self-adaptive Battery Management System (BMS)
- PV String Input:
- Max DC Input Power: 65,000W
- Max DC Input Voltage: 1,000V
- Start-Up Voltage: 180V
- MPPT Voltage Range: 150V - 850V
- Full Load DC Voltage Range: 450V - 850V
- Number of MPPT Trackers: 4
- PV Input Current: 36A + 36A + 36A + 36A
- Max Short Circuit Current: 55A + 55A + 55A + 55A
- Strings Per MPPT Tracker: 2
- AC Output:
- Rated Power / UPS Power: 50,000W
- Max AC Output Power: 55,000W
- Peak Power (Off-Grid): 1.5x rated power (10s)
- Rated AC Output Current: 75.8A / 72.5A
- Max AC Current: 83.3A
- Max Continuous AC Passthrough: 150A
- Output Frequency & Voltage: 50/60Hz, 220/380V, 230/400V
- Environmental Specifications:
- Operating Temperature: -40°C to 60°C
- Cooling: Smart air cooling
- Noise Level: ≤45 dB
- Protection Level: IP65
- Safety Certifications: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
Deye 50kW Hybrid Inverter Conclusion
The Deye 50kW Hybrid 3-Phase Inverter is a high-performance energy management solution for large-scale commercial and industrial solar installations. Its high-voltage battery compatibility, advanced MPPT technology, and smart monitoring make it an essential component for efficient and reliable solar power systems.
