Main Features
General Data
- Battery Type: Lithium-Ion
- Product Model: VOLTA STAGE 1
- Energy Nominal: 5.12KWH
- Nominal Voltage: 51.2VDC
- Capacity Nominal : 100AH
- Cell Type: LFP
- 1C/1C Continual Charge & Discharge
- Standard Charge Voltage: 56VDC
- Maximum Discharge Current: 100A
- Discharge Cut-Off Voltage: 44.8VDC
- Parallel Units: Maximum 8
- Design Life: 6000 Cycles @ 80% DOD @ 25°C
- Installation Type: Wall Mount & Floor Stand
Long cycle life Using high-quality lithium iron phosphate batteries, the cycle life is more than 6000 times at 80%DOD, and can be used for 10-15 years
High-quality prismatic lithium iron phosphate battery
Higher capacity, higher current, longer life
Low internal resistance and high current The low internal resistance of the battery, excellent continuous high current discharge performance
Intelligent BMS battery protection Built-in intelligent BMS (battery management system), effectively avoiding overcharging, over-discharge, overcurrent, short-circuit, balance and other problems
Communicated with multiple brands of inverters same time battery BMS supports simultaneous communication and docking with multiple brands of inverter
